Multilayer PCB Circuit Board FR4 Board Motherboard PCB Assembly HDI PCB Design PCBA for 8 OZ Electronic hardware. This is 4-layer PCB (PRINTED CIRCUIT BOARD) with FR-4, the main technical point is 8 OZ for the outer layer and 4 OZ for the inner layer. YMS PCB support heavy copper circuit board up to 12 OZ, our PRINTED CIRCUIT BOARD are widely used in electronic hardware application like:
Smart Meter PCB/Tele-Com PCB;
Gambling Board/Connector/Audio Frequency;
Security guard/LED Radiator/Setup Box/Automobile;
Touch Pad/Router/Air-conditioner/pole;
Solar energy/New energy battery board;
Palm Movie/Automobile-Light/Camera/Power Supply/Notebook Fan.

Send Inquiry

We have over 3400 customers all over the world from 64 countries.

multilayer pcb circuit board fr4 board motherboard pcb assembly hdi pcb design pcba for 8 oz electronics hardware4
Pls contact us at [email protected] for your PCB/FPC/PCBA/FPCA/STENCIL/ASSEMBLY service.

Product Parameters

Layer count: 4 layers
Material: FR-4 TG135
Copper: 8/4/4/8 OZ (heavy copper for inner and outer layer)
Outline Tolerance: +/-0.13mm
Board size: 182.6 x 164.52 mm
Minimum line width/line distance: 0.3mm/0.3mm (12mil/12mil)
Min hole: 0.3mm(12mil)
Thickness: 2.0mm±0.2mm
Surface treatment: Immersion Gold
Shaping form: CNC
Applications: Gambling Board/Connector/Audio Frequency

Product Feature

Heavy copper PCB (PRINTED CIRCUIT BOARD) products are widely used in power electronic equipment and power supply system.
Such PCB product has a finished copper weight of more than 4 OZ (140 um), compared to the standard PCB copper thickness which is 1 OZ.
Our thick copper PCB range:outer ≤ 12OZ, inner ≤ 8OZ.
