Electronic Custom Rigid-Flex Pcb With Electromagnetic Film + Dupont Material, Pcb Manufacturer From China Shenzhen

Electronic Custom Rigid-Flex PCB With Electromagnetic Film & Dupont Material, PCB Manufacturer From China Shenzhen. Rigid-Flex PCB Is Our Main Product From 2019, We Support Dupont Material, Also Material From Sheng Yi S1000-2, Panasonic.

Send Inquiry

electronic custom rigid flex pcb with electromagnetic film + dupont material pcb manufacturer from china shenzhen4

We Support 2-20 Rigid-Flex PCB, With 10 Layers Flex Area, With All Kinds Of Cover Lay thickness:28/50/60/80um, and support all kinds of stiffer like PI/FR4/steel.

Pls contact us at [email protected] for your PCB/FPC/PCBA/FPCA/STENCIL/ASSEMBLY service.

Product Details

Layer count	10
Material	FR-4(Sheng Yi) + PI(DuPont)
Board size(mm)	124 X 221
Stack up:	8(rigid) + 2(flex)
Board size(inch)	4.882 X 8.701
Board thickness	1.6mm(rigid) + 0.13mm(flex)
Outer layer copper	35um
Inner layer copper	18um
Min hole	0.1mm
Min trace width	3mil(0.075mm) for rigid board, 2mil(0.05mm) for flex board
Min trace gap	3mil(0.075mm) for rigid board, 2mil(0.05mm) for flex board
Surface treatment	Immersion gold (ENIG)
Application	semiconductor test equipment
Solder mask color	Green solder mask for rigid board + yellow cover lay for flex board
Silkscreen	white

Product Features

Rigid-flexible circuits (Rigid-flex PCB) is a circuit board that combines rigid PCB and flexible PCB (FPC) technology. It is used to achieve miniaturization for saving spacing, no need to use connectors, and can be welded with complex assembling. It’s widely used in cell phones, chemical equipment, industrial control products.

YMS PCB Support The Rigid-Flex PCB To The Below Application
battery protection boards, camera modules, and mobile phones, etc.

electronic custom rigid flex pcb with electromagnetic film + dupont material pcb manufacturer from china shenzhen5
