PCB—PRINTED CIRCUIT BOARD is our main product, we also support PCBA/FPC/FPCA/RIGID-FLEX PCB. Printed circuit board (PCB) mechanically supports and electrically connects electrical or electronic components using conductive tracks, pads, and other features etched from one or more sheet layers of copper laminated onto and/or between sheet layers of a non-conductive substrate. PCBs can be single-sided (L1), double-sided (L2), or multi-layer (L4+), YMS PCB can support up to 34 layers.
Multi-layer PCBs allow for much higher component density because circuit traces on the inner layers would otherwise take up surface space between components.
The rise in popularity of multilayer PCBs with more than two, and especially with more than four, copper planes was concurrent with the adoption of surface mount technology.
Pls contact us at [email protected] for your PCB/FPC/PCBA/FPCA/STENCIL/ASSEMBLY service.
| Layer count | 6 |
| Material | FR-4 |
| Board size(mm) | 122 X 15.43 |
| Board thickness | 1.8 mm |
| Outer layer copper | 1 OZ |
| Inner layer copper | 1 OZ |
| Min hole | 0.3mm |
| Min trace width | 5mil |
| Min trace gap | 5mil |
| Aspect ratio | 6:1 |
| Surface treatment | gold plating by electronic, not ENIG |
| Application | Industrial Control PCB |
| Solder mask color | BLACK |
| Silkscreen | WHITE |
| Standard | IPC-II, IPC-III, MIL |
| Certification | IS9001, IS14000, UL, SGS, TS16949 |
Our PCB products are widely used in the industrial control industry and systems. Most of them are used in power supplier, UPS, normally the product request 2 OZ or 3 OZ copper for the outer and inner layer.
