RF PCB (Radio Frequency) and Microwave PCBs are a type of PCB designed to operate on signals in the medium frequency to extremely high-frequency ranges (megahertz to gigahertz).
These ranges are used for communication signals in everything from mobile phones to military radars.
The materials used are advanced composites with very specific characteristics for dielectric constant (Er), loss tangent, and CTE (coefficient of thermal expansion). To meet increasing demands for Microwave & RF PCB, Printed Circuit Boards for our customers all over the world, we have increased our investment so that we have become a world-class manufacturer of PCBs using high-frequency laminates.
Pls contact us at [email protected] for your PCB/FPC/PCBA/FPCA/STENCIL/ASSEMBLY service.
Type: RF & Microwave PCB
Layer count: 12 layers
Material: FR-4 from TUC and Rogers 5880
Thickness: 1.6mm
Min. Hole Size: 0.2mm
Min. Line Width & Spacing: 4/4mil
Application: 5 G product and station/ cell phones and radar installations
Certificates: UL, RoHS, SGS, ISO9001 ISO14000 TS16949 IATF
Solder mask: blue
Silkscreen: white
Origin: YMS PCB from Shenzhen China
Normally, the PCB industry considers an RF circuit board to be any high-frequency PCB that operates above 100MHz.
Within the radio frequency class, anything above 2GHz is a Microwave PCB which they operate.
Microwave PCBs are classified as any RF circuit board operating above 2GHz.
Some of the suppliers of laminate / dielectric materials we utilize are Isola, NELCO 4000, Rogers & Taconic.
