Blue Tooth Board With Half Holes, Edge Holes.Pcb/Pcba/Fpc Assembly Shenzhen Supplier From China

Product Parameters

Layer count: 4 layers
Material: FR-4 TG150
Structure: standard 4 layer stack up
Outline Tolerance: +/-0.13mm
Board size: 19.5 x 22.12 mm
Minimum trace width: 0.1mm (4mil)
Minimum trace gap: 0.1mm (4mil)
Min hole: 0.2mm (8mil)
Thickness: 1.6mm ± 10% mm
Surface treatment: ENIG (immersion gold) 2u”
Standard: IPC-II/MIL/REACH
Lead time: 3-5 days
MOQ: NO
HS Code: 8534009000
Applications: Blue tooth equipment, GPS, UPS…
Impedance Control: Yes, 50ohms for single-end and 100 ohms for diff pair

Pls contact us at [email protected] for your PCB/FPC/PCBA/FPCA/STENCIL/ASSEMBLY service.

Material Feature

A.RIGID PCB
Laminate supplier: EMC, NAN YA, SHENG YI, ITEQ, ROGERS, PANASONIC
Laminate type: Halogen-free, Low DK
Laminate TG:TG135, TG150, TG170, TG180, TG250
Min core thickness mm: 0.04mm
Min Prepreg style mm: 1015 1027
Min board thickness (10-layer HDI): 0.62mm
Min board thickness (12-layer HDI): 0.72mm
HDI type: 2+N+2, 3+N+3, Any Layer

B.FPC
Base material supplier: DOOSHAN,THINFLEX,ITEQ,SHENG Yi, Dupont
Type: Halogen-free
Laminate TG: TG135,TG150,TG170,TG180,TG250
Min board thickness (Double-sided): 0.06mm
Coverlay supplier: DONGYI,OMAR,SHENG YI
PP supplier: DOOSHAN,WAZAM,SHENG YI

We support HDI PCB, FPC, RIGID-FLEX PCB, Double-side PCB, single-side PCB, multilayer PCB, IC TEST PCB, IC Substrate PCB.

Pls contact us at [email protected] for your PCB/FPC/PCBA/FPCA/STENCIL/ASSEMBLY service.
